Centre of gravity adjustment and ride performance go hand in hand on Catalyst 5Vx Wheelchair, The redesigned axle plate and rear frame give you 2" (5.08 cm) of centre of gravity adjustment in 1/2" (1.27 cm) increments and 5" (12.7 cm) of rear seat height adjustment over 7 positions. Find your fit, ease your propulsion and optimize the ride you've come to expect with Catalyst.
FREE Home Assessment
This Quickie Wheelchair includes a no obligation assessment, we cover all areas of mainland UK. We will visit you at home on a day and time to suit, with a demonstration model to familiarise yourself with. Your measurements will be taken by our expert to ensure the most perfect fit for you, Once your measurements have been taken, discussions can occur about additional features (if needed) with our expert to create a custom wheelchair that meets all your personal requirements! All you need to do is click on "Book A Home Demonstration" complete your details and we will do the rest, you can also choose to request a store demonstration should you prefer.
This price is based on standard configuration only. This item may have multiple additional extras that are not included in the published price. Pictures are for illustration only, please request a detailed quote.
• Transport Weight *13.9 lbs | 6.3 kg
• Standard Weight 24 lbs | 10.89 kg
• Seat Width 14 - 22" | 36 - 56 cm
• Seat Depth 14 - 20" | 36 - 51 cm
• Front Seat Height 13.5 - 21" | 34 - 53 cm
• Rear Seat Height 11.5 - 20" | 29 - 51 cm
• Top Frame Tubing Size 1" | 2.54 cm
• Bottom Frame Tubing Size 1.125" | 2.86 cm
• Axle Positions Available 7
• Centre of Gravity Adjustment Increments 5" | 1.27 cm
• Centre of Gravity Adjustment Range 2" | 5.08 cm
• Camber 1-4¬∞ (1¬∞ increments)
• Frame Material 7000 Series Aluminium
• HCPCS K0005
• Weight Capacity 300 lbs | 136.08 kg
• Weight Capacity HD350 lbs | 158.75 kg
* 16"x16" Frame, 5"x1" Poly Casters, Height Adjustable T-Arm Receivers. Footrest and Rear Wheels removed.
As a part of our ongoing product improvement initiative, We reserves the right to change specifications and design without notice. Further, not all features and options offered are compatible with all configurations of the wheelchair. Please consult for further more information.
Specifications
Max User Weight (kg)
124kg | 19stone
Total Weight With Batteries
5.6kg | 1stone
Style
Manual Folding
